ISPL 2410 Heavy-Duty Seal
ISPL 2410 is a balanced, double-acting multi-spring seal, mounted inside, built for high pressure. It suits chemical and acid pumps, and the falling-film evaporator and spent wash pumps of a sugar plant.
- Type
- Single, balanced
- Rotation
- Bi-directional
- Shaft size
- 25–200 mm0.98–7.87 in
- Pressure
- up to 20 kg/cm²≤ 20 kg/cm²up to 284 psi≤ 284 psi
- Temperature
- up to 180 °C≤ 180 °Cup to 356 °F≤ 356 °F
- Spring
- Multi-spring
Datasheet
Specifications
| Parameter | Limit | Unit | Copy |
|---|---|---|---|
| Shaft diameter | 25–2000.98–7.87 mmin | mmin | |
| Pressure | up to 20≤ 20up to 284≤ 284 kg/cm²psi | kg/cm²psi | |
| Temperature | up to 180≤ 180up to 356≤ 356 °C°F | °C°F | |
| Surface speed | up to [0.0]≤ [0.0] m/sft/s | m/sft/s | |
| Rotation | Bi-directional | – |
| Part | Options | Copy |
|---|---|---|
| 1 · Seal faces | [Face combinations] | |
| 2 · Springs | [Grade] | |
| 3 · Secondary seals | [Elastomer and PTFE options][Elastomer options] | |
| 4 · Gland plate | [Grade] | |
| 5 · Sleeve and other metal partsSleeve, metal parts | [Grades] |
Applications
Where it's used
Industries
Equipment
- Chemical pumps
- Acid and corrosive chemical pumps
- Falling-film evaporator pumps
- Fermented and spent wash pumps
Chemical pumps, acid and corrosive chemical pumps, falling-film evaporator pumps and fermented and spent wash pumps.
Design
Design features
-
Uniform face loading
Multiple springs press evenly on the face.
-
Balanced
The balanced primary ring suits high pressure.
-
Double acting
A double-acting design, mounted inside.
-
Heavy duty
Acids, corrosive chemicals and spent wash.
Files
Downloads
Datasheets open without a form. Drawings are sent on request.
FAQ
Questions buyers ask
Is it suitable for high pressure?
Yes. The balanced primary ring and multiple springs suit high-pressure duty. [Pressure limit to confirm by engineering]
What do you need from me to quote?
Shaft size, speed, temperature, pressure and the fluid. A photo of the old seal or its nameplate helps.
How long does delivery take?
After order confirmation: 2 days from stock, 2 weeks for a new seal.
